Display WW-11ALW – monitor of double circuit line without auxiliary power system

Backlight display 5 × 10 mm
Current input 4...20 mA
Aluminum, wall or pipe mounted casing
IP66
Intrinsic safety certificate

Displays
WW-11N type and WW-45 - monitors of two-wires circuit without auxiliary power system

Display
WW-30, WW-30T

4..20mA or 0...20mA current input (WW-30)
0..5V, 1..5V, 0..10V, 2..10V Voltage input (WW-30)
Pt100, Resistant input (WW-30T)
Power supply 230 V AC ą 10%

Digital indicators with relay outputs
PMS-920

Current input 4…20 mA or 0…20 mA
Voltage input 0…5V, 1…5V, 0…10V, 2…10V Pt100
2 or 4 settable relay outputs: 1 A, 250 V AC
Power supply 85…260 v AC/DC
Integrated power supply 24 V DC
RS-485 output

Digital indicator with relay outputs PMT-920

Input Pt100, Pt500, Pt1000 or K, S, J, T, N, R, B, E
2 settable relay outputs: 1 A, 250 V AC
Power supply 85…260 v AC/DC

Digital indicator with relay outputs
PMS-970T

Universal measuring input 4...20 mA, 0...20 mA or 0...10 V
4 relay outputs: 1 A, 230 V AC
4×7 mm LED display + 26-point bar graph
Integrated power supply 24 V DC
Additional options:
Power supply 24V AC/DC
passive current output
RS-485 digital output

Digital indicator with relay outputs
PMS-970P

Universal measuring input 4...20 mA, 0...20 mA or 0...10 V
4 relay outputs: 1 A, 230 V AC
4 × 20 mm red LED display
Integrated power supply 24 V DC
Additional options:
Power supply 24V AC/DC
passive current output
RS-485 digital output

Digital indicator with relay outputs
PMS-620N

4 × 20 mm red LED display
Universal measuring input 4…20mA, 0…20mA or 0…10V
Two relay outputs: 1 A, 230 V AC
RS-485 digital output
Integrated power supply 24 V DC
Wall mounted casing
